Receiver Approvals

brfc	title	author	version
3d7c2ca83a46	bsvalias Payment Addressing (Payee Approvals)	andy (nChain)	1

The Receiver Approvals specification extends both Basic Address Resolution and Sender Validation specifications by introducing a callback-based message flow and moving the payment destination process from a synchronous request-response flow to an asynchronous flow. Additional steps for the receiver are introduced, along with additional responses back to the sender, and additional demands on the capabilities of the sender's paymail service.

Capability Discovery

The .well-known/bsvalias document is updated to include a declaration of Receiver Approval flow support:

{
  "bsvalias": "1.0",
  "capabilities": {
    "3d7c2ca83a46": {
      "callback": "https://bsvalias.example.org/{alias}@{domain.tld}/payment-destination-response"
    }
  }
}

The capabilities.3d7c2ca83a46 object contains a callback property with a template endpoint URI for incoming payment destination request callbacks.

Changes to Basic Address Resolution and Sender Validation

• An additional response type with HTTP status code 202 (Accepted) is introduced. The body of the 202 response contains a token used to correlate a later callback from the receiver to the sender's paymail system with the initiating request from the sender

• The receiver's paymail system asynchronously notifies the receiver that the request has been received. The receiver is free to respond to the request at any time; that is to say this step is asynchronous and does not rely on the user being available at the time the request is received

  • The specific interaction between the receiver's paymail service and the receiver's client is beyond the scope of this specification

Flow

The Receiver Approval flow diagram detailed below does not include the Sender Validation steps in order to reduce diagrammatic complexity. These steps are mandatory and the flow is detailed in the Sender Validation specification.

Sender Request

There are no changes to the Sender Request as described in the Sender Validation specification.

Receiver Response

Existing 200, 401 and 404 responses remain unchanged.

202 Accepted

The request was received but further action from the receiver is required. The body of the 202 response MUST contain a correlation token for the sender to later match a callback from the receiver's system to a request initiated by the sender. The response content type MUST be application/json and MUST conform to the following schema:

{
  "token": "...",
  "signature": "..."
}

token MUST be unique across all requests. It is suggested that implementers use a token derivation function over the initiating request, for example the token could be a hex-encoded double-SHA256 hash of all fields of the request.

Sender systems are expected to annotate their local copy of the request with this token in order to match a response callback at some point in the future to the originating request.

The signature field MUST contain a valid Bitcoin message signature over the UTF8 byte string content of the token field that senders MUST validate against the receiver's public key. The message digest process and signature encoding scheme is unchanged from that defined in Basic Address Resolution.

Receiver Callback

The capabilities.3d7c2ca83a46.callback path of the sender's .well-known/bsvalias document returns a URI template. Receivers should replace the {alias} and {domain.tld} template parameters with the values from the receiver's paymail handle and then make an HTTP POST request against this URI.

The request MUST have a content type of application/json and MUST conform to the following schema:

{
  "token": "...",
  "output": "...",
  "signature": "..."
}

The token field contains the same token as returned from be Receiver's paymail service during the 202 response.

The output field is unchanged from Basic Address Resolution.

The signature field is added and MUST contain a valid Bitcoin message signature over the UTF8 byte string content of the concatenation of the token and output field that senders MUST validate against the receiver's public key. The message digest process and signature encoding scheme is unchanged from that defined in Basic Address Resolution.

Rejected Requests

No callback is specified for rejections. Sender clients receive no information about a rejected request. A rejection and an outstanding request are, by design, indistinguishable.
